Performance | ||
Layer | Layer 2 | |
Managed | Yes | |
Switching Capacity | 8.8 Gbps | |
Packet Forwarding Rate | 5.36 Mpps | |
Packet Buffer Memory | 2.75 Mbit | |
MAC Table Size | 4K | |
Communication Standard | IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE 802.3ab;
IEEE 802.3z |
|
Hardware Feature | ||
Standard Power Supply | Yes | |
PoE | Yes | |
Ethernet Port | 16 | |
Optical Port | 2 | |
Ethernet Port Rate | 100 Mbps | |
Optical Port Rate | 1 Gbps | |
Number of Bussiness Card Slots | Port 1-16: 16 × RJ-45 10 M/100 M (PoE) Port 17-18: 2 × RJ-45 10 M/100 M/1000 M (uplink) Port 17-18: 2 × SFP 1000 M (uplink) (combo) |
|
Debugging | Console × 1 | |
Power Supply | 100V–240V AC | |
Operating Temperature | –10 °C to +55 ° (14 °F to 131 °F) | |
Operating Humidity | 10% RH–90% RH | |
Power Consumption | Idling: 10W Full load: 190W |
|
PoE | ||
PoE Standard | IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt | |
PoE Budget | Port 1-2 ≤ 90W, Port 3-16≤ 30W, total ≤ 190W | |
PoE Pin Assignment | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) | |
PoE Management | Power consumption management Power on and power off Power down for overload Green PoE Legacy support |
|
Long Distance PoE Transmission | 250 m long-distance power supply | |
Function | ||
Spanning Tree Protocol | IEEE 802.1d (STP); 802.1w (RSTP) | |
VLAN | IEEE802.1q Standard VLAN | |
Flow Control | Support IEEE 802.3x (full duplex flow control) and back pressure flow control (half duplex) | |
Link Aggregation | Static; LACP | |
Port Mirroring | One-to-one; multiple-to-one | |
Multicast | GMP snooping based on port | |
DHCP | DHCP client | |
Security | Hardware supports IP and MAC binding based on port, MAC filtering based on port, and IEEE802.1x port authentication | |
QoS | High and low priority WRR 802.1P DSCP Priority based on protocol |
|
General | ||
ESD | Air discharge: 8kV Contact discharge: 6kV |
|
Thunder-proof | Common mode: 4kV Differential mode: 2kV |
|
Dimensions | 440 mm × 300 mm × 44 mm (17.32″ × 11.81″ × 1.73″) (L × W × H) | |
Packaging Dimensions | Packing box: 528 mm × 412 mm × 112 mm (20.79″ × 16.22″ × 4.41″) (L × W × H) Protective box: 584 mm × 549 mm × 446 mm (22.99″ × 21.61″ × 17.56″) (L × W × H) |
|
Transmission Performance: | ||
Switch power supply voltage 53V.
CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m |
||
Cable(m) | Load Capacity(W) | Bandwidth(Mbps) |
IEEE802.3bt 90 W | ||
100 | 71.3 | 100 |
150 | 62 | 10 |
200 | 51 | 10 |
250 | 40 | 10 |
Hi-PoE 60 W | ||
100 | 53 | 100 |
150 | 50 | 10 |
200 | 47 | 10 |
250 | 37 | 10 |
IEEE802.3at 30 W | ||
100 | 25.5 | 100 |
150 | 25.5 | 10 |
200 | 25.5 | 10 |
250 | 25.5 | 10 |
