Hardware | |
Data Transmission Port | 4 PoE ports with 10/100 Mbps Base-TX 2 uplink ports with 10/100Mbps Base-TX |
Power Supply | AC100–AC240V |
Operating Temperature | -10°C to +55°C (-14°F–131°F) |
Operating Humidity | 10%–90% |
Power Consumption | Idling: 0.5W Full load: 36W |
PoE | |
PoE Budget | Port1-4 ≤30W, whole PoE budget ≤36W |
PoE Standard | IEEE802.3af, IEEE802.3at |
PoE Pin Assignment | PoE: 1, 2, 4, 5(V+), 3, 6, 7, 8(V-) |
Performance | |
Switching Capacity | 1.2 Gbps |
Packet Forwarding Rate | 0.89 Mpps |
MAC Table Size | 2 K |
Jumbo Frame | 2048 byte |
Communication Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3X |
Performance | |
ESD | Air discharge: 8kV Contact discharge: 6kV |
Thunderproof | Common mode: 6kV Differential mode: 4kV |
Net Weight | 0.56 kg (1.23 lb) |
Gross Weight | 1.11 kg (2.15 lb) |
Product Dimensions (W × L × H) |
194.0 mm × 108.1 mm × 35.0 mm (7.64″ × 4.26″ × 1.38″) |
Packaging Dimensions (W × L × H) |
Packing box: 303 mm × 262 mm × 72 mm (11.92″ ×10.31″ × 2.83″)
Protective box: 549 mm × 325 mm × 397 mm (21.61″ ×12.80″ × 15.63″) |
