| Camera | |||||
| Image Sensor | 1/2.7″ CMOS | ||||
| Max. Resolution | 3200 (H) × 1800 (V) | ||||
| ROM | 128 MB | ||||
| RAM | 256 MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||
| Min. Illumination | 0.007 lux@F1.6 (Color, 30 IRE);
0.0007 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on) |
||||
| S/N Ratio | >56 dB | ||||
| Illumination Distance | Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light) |
||||
| Illuminator On/Off Control | Auto;Manual | ||||
| Illuminator Number | 1 (Multi-core (IR + warm) light) | ||||
| Angle Adjustment | Pan: 0°–360°;
Tilt: 0°–90°; Rotation: 0°–360° |
||||
| Lens | |||||
| Lens Type | Fixed-focal | ||||
| Lens Mount | M12 | ||||
| Focal Length | 2.8 mm; 3.6 mm | ||||
| Max. Aperture | F1.6 | ||||
| Field of View | 2.8 mm: H: 110°; V: 58°; D: 132°
3.6 mm: H: 91°; V: 46°; D: 110° |
||||
| Iris Control | Fixed | ||||
| Close Focus Distance | 2.8 mm: 1.1 m (3.61 ft)
3.6 mm: 1.7 m (5.58 ft) |
||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.8 mm | 63.6 m
( 208.66 ft) |
25.4 m
( 93.33 ft) |
12.7 m
( 41.67 ft) |
6.4m
( 21.00 ft) |
|
| 3.6 mm | 85.4 m
( 280.18 ft) |
34.2 m
( 112.20 ft) |
17.1 m
( 56.10 ft) |
8.5 m
( 27.89 ft) |
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |||||
| Intelligence | |||||
| Human Detection | Support the classification and accurate detection of human | ||||
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | ||||
| Video | |||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | ||||
| Smart Codec | Smart H.265+; Smart H.264+ | ||||
| Video Frame Rate | Main stream: 3200 × 1800@(1–20 fps)/2688 × 1520@(1–25/30 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
||||
| Stream Capability | 2 streams | ||||
| Resolution | 6M (3200 × 1800); 4M (2880 × 1620/2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||
| Bit Rate Control | VBR;CBR | ||||
| Video Bit Rate | H.264: 32 kbps–8192 kbps;
H.265: 12 kbps–8192 kbps |
||||
| Day/Night | Auto(ICR)/Color/B/W | ||||
| BLC | Yes | ||||
| HLC | Yes | ||||
| WDR | DWDR | ||||
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | ||||
| Gain Control | Auto/Manual | ||||
| Noise Reduction | 3D NR | ||||
| Motion Detection | OFF/ON (4 areas, rectangular) | ||||
| Region of Interest (RoI) | Yes (4 areas) | ||||
| Smart Illumination | Yes | ||||
| Smart Dual Light | Yes | ||||
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) | ||||
| Mirror | Yes | ||||
| Privacy Masking | 4 areas | ||||
| Audio | |||||
| Built-in MIC | Yes, built-in Mic | ||||
| Audio Compression | G.711a; G.711Mu; PCM; G.726 | ||||
| Alarm | |||||
| Alarm Event | Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception | ||||
| Network | |||||
| Network Port | RJ-45 (10/100 Base-T) | ||||
| SDK and API | Yes | ||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P | ||||
| Interoperability | ONVIF (Profile S & Profile T); CGI | ||||
| User/Host | 20 (Total bandwidth: 48 M) | ||||
| Storage | FTP | ||||
| Browser | IE; Chrome; Firefox | ||||
| Management Software | Smart PSS Lite; DSS; DMSS; DoLynk Care | ||||
| Mobile Client | iOS;Android | ||||
| Cyber Security | Video encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;Generation and importing of X.509 certification;HTTPS;Trusted boot;Trusted execution;Trusted upgrade | ||||
| Certification | |||||
| Certifications | CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
||||
| Power | |||||
| Power Supply | 12 VDC/PoE (802.3af) | ||||
| Power Consumption | Basic: 2 W (12 VDC), 2.9 W (PoE);
Max.: 4 W (12 VDC), 5.3 W (PoE) (H.265 + intelligence on+ DWDR + illuminator intensity) |
||||
| Environment | |||||
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||
| Operating Humidity | ≤95%(RH), non-condensing | ||||
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | ||||
| Storage Humidity | ≤95%(RH), non-condensing | ||||
| Protection | IP67 | ||||
| Structure | |||||
| Casing Material | Metal | ||||
| Product Dimensions | 173.3 mm × 70.0 mm × 70.0 mm (6.82″ × 2.76″ × 2.76″) (L × W × H) | ||||
| Net Weight | 0.44 kg (0.97 lb) | ||||
| Gross Weight | 0.55 kg (1.21 lb) | ||||
