Specifications:
| Camera(2.8 mm +6 mm) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Fixed Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Sensor | 1/3.2” CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Resolution | 2304 (H) × 1296 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illumination Distance | Up to 30 m (98.43 ft) (IR) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator Number | 2 (IR LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Angle Adjustment | 0° to 15° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lens Type | Fixed-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Focal Length | 2.8 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Aperture | F2.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Field of View | H: 90°; V: 50°; D: 105° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| PT Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Sensor | 1/3.2” CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Resolution | 2304 (H) × 1296 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illumination Distance | Up to 50 m (164.04 ft) (IR)
Up to 40 m (131.23 ft) (Warm light) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator Number | 2 (IR LED); 1 (Warm light) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Angle Adjustment | Pan: 0° to 349°
Tilt: –5° to 90° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
