Specification
- Door station/Video parameters
- Supplement light IR light, up to 3 m
- Resolution Stream resolution: 1280 * 720@60fps
- FOV Horizontal: 130°,Vertical: 70°
- Door station/Audio parameters
- Audio input Built-in omnidirectional microphone
- Audio output Built-in loudspeaker
- Door station/Device interfaces
- Lock control1 relay, max 30V 1 A
- Debugging port1
- Four-wire1 four-wire interface
- Door station/General
- Button1 physical button(s)
- Indicator/
- Power supply12 VDC
- Power consumption Max. 4W
- Working temperature-30° C to + 60° C
- Working humidity10% to 90%
- Dimensions136mm x 51mm x 20mm
- Application environment Indoor
- Installation Surface mounting
- Protective level/
- Material Plastic
- Indoor station/Display parameters
- Operation method Physical button
- Type7-inch colorful TFT
- Resolution1024 x 600
- Indoor station/Audio parameters
- Audio input Built-in omnidirectional microphone
- Audio output Built-in loudspeaker
- Indoor station/Capacity parameters
- Linked indoor extensions capacity2
- Linked doorphone capacity2
- Linked analog camera1
- Indoor station/Device interfaces
- Power supply input12V DC
- Debugging port1
- Four-Wire interface4, 2 for indoor extentions, 2 for door phones
- DIP switch1 Bit
- BNC1
- Indoor station/General
- Button4 physical button
- Power supply12 VDC
- Power consumption≤5 W
- Working temperature-10° C to + 55° C (14° F to 131° F)
- Working humidity10% to 90%
- Dimensions (W × H × D)178mm x 132mm x 19mm
- Installation Surface mounting
- Application environment Indoor
