Specification:
Door station/Video parameters
Supplement light; IR light, up to 3 m
Resolution Stream; resolution:1280 * 720@60fps
FOV; Horizontal: 117°, Vertical: 70°, Diagonal: 141°
Door station/Audio parameters
Audio input; 1 built-in omnidirectional microphone
Audio output; 1 built-in loudspeaker
Door station/Capacity parameters
Linked indoor station capacity: 3
Sub door station capacity: 1
Card capacity: /
Door station/Device interfaces
Lock control: 1 relay, max 30 V 1 A
Power supply input: 12 VDC
Debugging port: 1
Four-Wire interface: 1
Door station/General
Button: 1 physical button(s)
Indicator: /
Power supply: 12 VDC
Power consumption ≤ 4 W
Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
Working humidity: 10% to 90% (no-condensing)
Application environment: Outdoor
Dimension (W × H × D): 55 mm × 145 mm × 24 mm (2.17″ × 5.71″ × 0.94″)
Installation: Surface mounting
Protective level: IP65, IK08
Material: Aluminum alloy and Plastic
Without package: 200 g (0.44 lb)
Indoor station/System parameters
Operation system: Embedded Linux operation system
RAM: 128 MB
ROM: 32 MB
Processor: Embedded high performance processor
Indoor station/Display parameters
Type: Colorful TFT
Resolution: 1024 × 600
Viewing Angle: Horizontal 160°, vertical 130°
Contrast: 700 (Typ)
Luminance: 250 cd/m² (Typ)
Operating method: Capacitive touch screen
Screen size: 7-inch
Indoor station/Audio parameters
Audio input: 1 built-in omnidirectional microphone
Audio output: 1 built-in loudspeaker
Audio compression bitrate: 64 Kps
Audio compression standard: G.711U, G.711A
Audio quality: Noise suppression and echo cancellation
Indoor station/Capacity parameters
Linked network camera capacity: /
Linked indoor extensions capacity: 2
Linked doorphone capacity: 2
Linked analog camera: 1
Indoor station/Network parameters
Wi-Fi: Wi-Fi 802.11 b/g/n
Indoor station/Device interfaces
Network interface: /
RS-485: /
Alarm input: 2
Alarm output: /
Power supply input: 12 VDC
TF card: Support TF card, up to 128 G
Debugging port: 2
Four-Wire interface: 4
Relay: /
Indoor station/General
Button: 0 physical button
Power supply: 12 VDC
Power consumption ≤ 5 W
Working temperature: -10 °C to 50 °C (14 °F to 122 °F)
Working humidity: 10% to 90% (no-condensing)
Dimension (W × H × D): 175 mm × 113.5 mm × 18.1 mm (6.89″ × 4.47″ × 0.71″)
Installation: Surface mounting
Application environment: Indoor
Without package: 260 g (0.573 lb)
Language: English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian, Latvian, Traditional Chinese
